Home > Products > White Color Aluminum Foil

White Color Aluminum Foil

Series: AA1100, 3003, 3004, 3105, 5006, 5052, 8011, etc.

Thickness: 0.016-1.5mm

Width: <1600mm

Warrantly   :  Regular PE: 3-5 years ;

                         High Performance PE: 6-9 years;

                         PVDF: 15 years ;

                         FEVE: Two coats: between 10-15 years ;

                         FEVE: Three coats: 15-20 years

Application: aluminum composite panel, aluminum honeycomb, fireproof veneer, aluminum ceiling, shutters, roller shutter door, etc.


Product Description

What is color coated aluminum coil?

Color coated aluminum coil is a type of aluminum coil that has gone through a coating process to give it color and added protection. The coating can come in a variety of colors and is applied using a roll coating process that ensures even distribution. The result is a durable, corrosion-resistant material that is ideal for a wide range of applications, including construction, transportation, and electronics. Color coated aluminum coil is also highly versatile and can be shaped and cut to meet the specific needs of any project, making it a popular choice for architects, designers, and builders around the world.

Product Name

Color Aluminum Coil

Technical Standard

ASTM,GB/T3280-2007,JIS,DIN,BS ,AS etc

Material of substrate

Aluminum Coil(1060/1100/3003/3004/3105/5052)

Thickness

0.018mm-1.5mm

Width

600mm-1270mm ( 914 / 1000 / 1200 /1220 / 1250mm)

Inside diameter of aluminum coil

508mm or 610mm

Color coat paint

Primer

HDPE

PE

PVDF

epoxy resin



Color coating thickness range

Top paint: 5+ 8μm --5+ 20μm;

Back paint: 5-24μm (usually 5-7μm)

Color

Based on color chart/sample

Surface

Smooth/embossed

aluminum roll gross weight

1MT-3 MT (general1.5 MT)

Packing

Export packaging by sea, or according to

customer requirements.

port of loading

Qingdao

Application

Industrial panels, roofing tiles and painted wall panels.

FAQ - Color Coated Aluminum Coil

Q: What is color coated aluminum coil?

A: Color-coated aluminum coil is a building material product formed by spraying color paint on the surface of aluminum sheet after special treatment, which is usually used to decorate the exterior wall, roof, interior wall and other parts of the building.

Q: What are the characteristics of color-coated aluminum coil?

A: The color coated aluminum coil has the characteristics of bright color, flat surface, corrosion resistance, strong weather resistance, easy to clean, light weight and so on. At the same time, it also has strong plasticity and can be processed into various shapes to meet different architectural decoration needs.

Q: What are the thicknesses of color-coated aluminum coils?

A: The thickness of the color coated aluminum coil is generally between 0.2mm and 3.0mm. Depending on the use scenario of different thickness, some products may have more specific requirements, which need to be negotiated with the supplier.

Q: What is the color and color stability of color-coated aluminum coil?

A: Color-coated aluminum rolls can be customized in different colors according to customer needs. Color stability is good, even if exposed for a long time, the color is not easy to change.

Q: What is the production process of color coated aluminum coil?

A: The production process of color coated aluminum coil usually includes aluminum plate cutting, surface treatment, primer spraying, painting spraying, curing and other processes. The whole production process needs to ensure the quality of materials and the rigor of the process.

Q: What are the application fields of color coated aluminum coil?

A: Color-coated aluminum rolls are usually used in architectural decoration, advertising signs, interior decoration and other fields. In architectural decoration, it can be used for external wall curtain wall, internal wall, ceiling, roof, sun room, etc. In terms of advertising signs, it can be used to make large billboards; In interior decoration, it is often used to decorate ceilings, walls, columns and other parts.
